01.152021CIVA SHM: Structural Health Monitoring thanks to simulation!Category "CIVA Software" | No comment

CIVA SHM

Since Structural Health Monitoring (SHM) sensors are embedded in the monitored structure, it is even more important than in traditional NDE to design and qualify them carefully before implementation. Simulation is a must have! CIVA now includes a new module to model SHM by Guided Waves, CIVA SHM.

Based on an innovative technique providing very competitive computation times, CIVA SHM is a must-have tool for SHM engineers. With CIVA SHM, engineers can lower the need for costly and time-consuming mock-ups:

  • Design monitoring strategy: Define the relevant number of sensors before preparing prototypes and then embedding sensors in a real structure… For life!
  • Demonstrate monitoring performance: Study influential parameters to assess and improve SHM system reliability
  • Provide data sets for POD evaluation: Generate massive data at low cost thanks to modelling for Probability of Detection campaigns
  • Better understand SHM signals: Simulate different scenarios to better identify defect signals from other features and geometrical effects

In an easy-to-use dedicated user interface, you can represent the specimen to be monitored, the network of sensors and the target defects, then CIVA SHM computes the sensor responses. Dispersion curves are also provided.

CIVA SHM can simulate metallic or composite stratified planar components with potential curvatures or stiffener as well as metallic pipe configurations.

More information available in this document.

Feel free to contact us if you need to have more information about this new module!

The EXTENDE team.

12.092020Easily demonstrate and train on your flaw detector with our TraiNDE UT virtual mock-upCategory "TraiNDE" | No comment

TraiNDE UT Device Connected

Whatever the UT flaw detector you wish to use, TraiNDE UT Device Connected provides you with a virtual mock-up solution to train on your flaw detector or demonstrate its features without carrying heavy blocks!

Fueled with a variety of educational and industrial exercises (welds, calibration and sensitivity blocks, blind blocks, plates, etc.) as well as educational tools (section view, gate triggering view, zone coverage, etc.), TraiNDE UT Device Connected provides you with a highly portable solution to maximize training efficiency and practice anywhere at any time!

Have a look at our video about the Device Connected option, and visit our dedicated website.

Do not hesitate to contact us to get an offer for TraiNDE UT with this new outstanding option!

The EXTENDE team.
